Narrow your search by using the "filters" below.
Model No.
52001
52003
52004
52005
52006
52007
52008
52009
52010
52011
52013
63702
63703
63706
Thread Size
1"-8
1/2"-13
1/4"-20
1/4"-28
10-32
10mm x 1.50
3/8"-16
5/16"-18
5/8"-11
6-32
8-32
8mm x 1.25
B
1-1/2"
1"
1-1/4"
1-1/8"
17/32"
2-13/32"
3/4"
5/8"
22mm
C
0.062
0.093
0.125
0.187
0.25
0.312
0.500
3mm
D
0.046
0.07
0.093
0.119
0.135
0.186
0.248
0.31
0.499
3.5
4
End Force Initial
1.5
2.0
2.7
2.9
25 (5.62)
3.0
5.5
6.6
10.5
16.0
9 (2.02)
End Force Final
4.5
7.3
9.0
11.1
13.0
14.5
15.0
17.4
25.5
35 (7.87)
68.0
70 (15.74)

Standard Spring

Standard Spring
 More Info   Model No.   Thread Size   B   C   D   End Force Initial   End Force Final   Brand   Price   Buy Now

52001

52001 6-32 17/32" 0.062 0.046 1.5 4.5 TE-CO  $4.39

52003

52003 8-32 5/8" 0.093 0.07 2.7 7.3 TE-CO  $4.39

52004

52004 10-32 3/4" 0.125 0.093 2.9 11.1 TE-CO  $4.22

52005

52005 1/4"-20 1" 0.187 0.119 3.0 13.0 TE-CO  $4.22

52006

52006 1/4"-28 1" 0.187 0.119 3.0 13.0 TE-CO  $4.22

52007

52007 1/4"-20 3/4" 0.125 0.119 2.0 9.0 TE-CO  $4.22

52008

52008 5/16"-18 1" 0.187 0.135 3.0 15.0 TE-CO  $4.22

52009

52009 3/8"-16 1-1/8" 0.187 0.186 5.5 14.5 TE-CO  $4.22

52010

52010 1/2"-13 1-1/4" 0.25 0.248 6.6 17.4 TE-CO  $4.39

52011

52011 5/8"-11 1-1/2" 0.312 0.31 10.5 25.5 TE-CO  $5.68

52013

52013 1"-8 2-13/32" 0.500 0.499 16.0 68.0 TE-CO  $11.59

63702

63702 8mm x 1.25 22mm 3mm 3.5 25 (5.62) 70 (15.74) TE-CO  $5.63

63703

63703 10mm x 1.50 22mm 3mm 4 25 (5.62) 70 (15.74) TE-CO  $5.79

63706

63706 8mm x 1.25 22mm 3mm 3.5 9 (2.02) 35 (7.87) TE-CO  $5.63
Displaying 1 to 14 (of 14 products) Result Pages:  1
